3/2 DIRECT ACTING SOLENOID VALVE WITH AC220V COIL

3/2 DIRECT ACTING SOLENOID VALVE WITH AC220V COIL

Size
Have questions about orders, wholesale pricing, or bulk inquiries?

3/2 Direct Acting Solenoid Valve is a compact and high performance valve used to control the flow of air in pneumatic systems. The valve is direct acting type (poppet type), normally closed (NC), energized to open. Suitable for various industrial automation applications.

Specifications

Model
:
3V 025 06
Valve Type
:
3/2 Way, Direct Acting (Normally Closed
Port Size
:
1/8", 1/4" BSPP
Orifice Size
:
2.5 mm
Working Medium
:
Air (Filtered by 40μm filter element)
Operating Type
:
Direct Acting (Poppet Type)
Working Pressure
:
0 0.8 MPa (0 ~ 114 psi)
Max. Pressure
:
1.0 MPa (145 psi)
Ambient Temperature
:
-5 ~ +50 °C
Voltage
:
AC220V 50/60Hz
Power Consumption
:
4.5VA (AC220V)
Insulation Class
:
Class B
Protection Class
:
IP65 (DIN 40050)
Duty Cycle
:
100% ED
Body Material
:
Aluminum Alloy
Seal Material
:
NBR
Response Time
:
≤ 20 ms
Installation
:
Any Position
Weight (Approx.)
:
0.12 kg.
